医疗用内窥镜设备定期保养

Regular maintenance of medical endoscope equipment

医疗用内窥镜设备定期保养一般由仪管员配合工程技术人员完成，它是一项不断循环进行的有组织有计划的维修措施，这有利于掌握仪器的运行规律，有利于出现故障后的查找：定期保养的内容和时间，不同仪器有不同的做法.一般可以分3个等级：

Regular maintenance of medical endoscope equipment is generally carried out by instrument managers in collaboration with engineering technicians. It is an organized and planned maintenance measure that is continuously circulated, which is conducive to mastering the operating rules of the instrument and finding faults. The content and time of regular maintenance vary depending on the instrument. Generally, it can be divided into three levels:

(1)一保：一般可以一个月至一个季度进行一次.主要内容除厂日常维护的工作外，可以拆开机壳，各处积尘，污垢、异物、紧固螺丝、添加润滑剂;检查务器件、元件有无磨损、变形、烧蚀、击穿、松动，受潮，老化、接地等情况;检测各组电源电压及纹波，检查高压部件运行和接触情况等;

(1) First maintenance: Generally, it can be carried out once a month to once a quarter. In addition to daily maintenance work in the factory, the main content can be to disassemble the casing, collect dust, dirt, foreign objects, tighten screws, and add lubricants in all places; Inspect the service components for wear, deformation, erosion, breakdown, looseness, moisture, aging, grounding, and other conditions; Detect the voltage and ripple of each group of power supplies, check the operation and contact conditions of high-voltage components, etc;

(2)二保：一般可以半年至一年进行一次。主要内容除做好一保外，可以对整机控制台上的各个仪表及操作控制系统的灵敏度，精度进行测试校正和计量检定，更换高压发生器绝缘汕等到期的损耗品，对电路中各测试点的电压，波形进行系统检测和做拉偏试验;

(2) Secondary insurance: Generally, it can be carried out once every six months to a year. The main content is not only to ensure the safety of the equipment, but also to test, calibrate, and calibrate the sensitivity and accuracy of various instruments and operating control systems on the control console of the entire machine, replace expired loss products such as high-voltage generator insulation, and conduct systematic testing and bias testing of the voltage and waveform at various test points in the circuit;

(3)三保：一般可以2-4年进行一次：主要内容除做好二保外，必要寸可以将整机进行全部拆卸子以清洗检修，超过使用期的元器件应尽量更换或修复，应对仪器进行较为彻底的调试，恢复其工作精度和性能，达到或超过新机的程度是完全有可能的。

(3) Three guarantees: Generally, it can be carried out once every 2-4 years. In addition to ensuring the second guarantee, the entire machine can be fully disassembled for cleaning and maintenance if necessary. Components that exceed the service life should be replaced or repaired as much as possible. The instrument should be thoroughly debugged to restore its working accuracy and performance, and it is entirely possible to achieve or exceed the level of a new machine.

医疗用内窥镜的清洗维护

Cleaning and maintenance of medical endoscopes

内窥镜设备维修人员提醒您，医疗用内窥镜操作时动作要轻柔，旋转弯曲角手柄要缓慢地操作，用力要均匀，勿用暴力或力量过大。弯曲部在被“固定”的情况下，不要转动弯曲手柄，否则将折断牵引钢丝[1]。手持摄像头时，要紧握摄像头及柄的关节位，忌握线束和垂吊关节位，否则将损坏玻璃纤维束。

The maintenance personnel of the endoscope equipment remind you that when operating medical endoscopes, the action should be gentle, the bending angle handle should be rotated slowly, and the force should be even. Do not use violence or excessive force. When the bending part is "fixed", do not turn the bending handle, otherwise it will break the traction steel wire [1]. When holding a camera, it is necessary to firmly grasp the joint position of the camera and handle, and avoid grasping the wiring harness and hanging the joint position, otherwise it will damage the fiberglass bundle.

在手术过程中光纤内窥镜器械使用后应及时用无菌水擦净血迹，切忌将器械拆开浸泡以免丢失或体内。还有什么事项就来我们网站http://www.jiangrenyiliao.cn咨询!

During the surgical process, the fiber optic endoscope instrument should be promptly wiped clean with sterile water after use, and the instrument should not be opened and soaked to avoid loss or damage to the body. If there are any other matters, please come to our website http://www.jiangrenyiliao.cn consulting service
