With the continuous development of medical technology, medical endoscopy has been widely used in the medical field, it has become an indispensable important medical instrument in clinical diagnosis and treatment. It has become an important link in the hospital infection management to strengthen the infection management of endoscopes and do a good job in the disinfection of endoscopes. Next, the small edition of endoscope equipment maintenance will give you a general introduction.

　　内窥镜的组成与分类

　　Composition and classification of endoscope

　　医用内窥镜由三大部分构成：内窥镜系统，图像显示系统，照明系统，内窥镜按成像构造可分为硬管式内窥镜、光学纤维内窥镜、电子内窥镜；根据其功能又可分为消化道内窥镜、呼吸系统内窥镜、泌尿系统内窥镜等。

　　Medical endoscope consists of three parts: endoscope system, image display system, lighting system. Endoscope can be divided into hard tube endoscope, optical fiber endoscope and electronic endoscope according to imaging structure; according to its function, it can also be divided into digestive tract endoscope, respiratory system endoscope, urinary system endoscope, etc.

　　1、纤维内窥镜

　　1. Fiberscope

　　2、电子内窥镜

　　2. Electronic endoscope

　　3、医院内窥镜系统

　　3. Hospital endoscopy system

　　引起内窥镜感染的原因

　　Causes of endoscopic infection

　　1.内窥镜通道与附件难以消毒；2.自动清洗剂污染；3.消毒剂使用不当；4.内通道未干燥；5.未知原因。

　　1. It is difficult to disinfect the endoscope channel and accessories; 2. The automatic cleaning agent is polluted; 3. The disinfectant is not used properly; 4. The internal channel is not dry; 5. Unknown reasons.

　　引起内窥镜感染原因分析

　　Causes of endoscopic infection

　　《中国消毒学杂志》报道因内窥镜检查引起的377位感染病例，其中上消化道镜占47.75%，下消化道引起的占26.79%，支气管镜引起的占25.46%。

　　The Chinese Journal of disinfection reported 377 cases of infection caused by endoscopy, of which 47.75% were caused by upper digestive tract, 26.79% by lower digestive tract and 25.46% by bronchoscope.

　　内窥镜感控解决方案

　　Endoscope sensing solution

　　1、医院内窥镜的清洗消毒分为外部硬件系统和各类内镜两部分，外部硬件系统包括图像处理器、监视器、冷光源等可以采用伽玛无醇卫生湿巾擦拭即可。

　　1. The cleaning and disinfection of endoscopes in hospital can be divided into two parts: external hardware system and all kinds of endoscopes. The external hardware system including image processor, monitor, cold light source, etc. can be wiped with gamma alcohol free sanitary wipes.

　　2、 硬镜消毒步骤：1.将硬镜放于容器上，清洗和浸泡时与其他手术器械分开盛装；2.采用微可清多酶全效清洗剂清洗，使用柔软、干净的小刷子、海绵或者小纱布；3.清洗完后用干净的纱布擦干外表面水分；4.对擦干后的硬件进行高温蒸汽消毒，且术前与其他器械分开摆放。

　　2、 Steps of hard mirror disinfection: 1. Place the hard mirror on the container and separate it from other surgical instruments when cleaning and soaking; 2. Clean it with micro cleanable multi enzyme full effect cleaner and use soft and clean small brush, sponge or small gauze; 3. Dry the surface water with clean gauze after cleaning; 4. Sterilize the dried hardware with high temperature steam and separate it from other instruments before operation put.

　　3、软镜定时消毒方法：使用二氧化氯消毒（一扫清，泡腾片）对软镜定时消毒（1）将整条软镜管道注入空气，排掉清水，防止水分稀释消毒液；（2）将软镜放入消毒液中完全浸泡，用一次性注射器把消毒液注入所有管道直到无气泡冒出；（3）将软镜、附件和清洗工具浸泡在消毒液中，直到规范要求的浸泡时间为止；（4）浸泡结束后用注射器注入空气排除多余消毒液，排除多余消毒液，取出内镜。

　　3. Timing disinfection method of soft mirror: use chlorine dioxide disinfection (one sweep, effervescent tablet) to timing disinfection of soft mirror (1) inject air into the whole soft mirror pipe, drain off the water, prevent water from diluting the disinfectant; (2) put the soft mirror into the disinfectant and soak it completely, inject the disinfectant into all pipes with a disposable syringe until no bubbles emerge; (3) clean the soft mirror, accessories and cleaning Soak the tools in the disinfectant until the immersion time required by the specification; (4) after the immersion, inject air into the syringe to remove the excess disinfectant, remove the excess disinfectant, and take out the endoscope.

　　以上是内窥镜感染清洁消毒的方法，想要了解更多欢迎咨询内窥镜设备维修官网http://www.jiangrenyiliao.cn。

　　The above is the cleaning and disinfection method of endoscopic infection. If you want to know more, please consult the official website of endoscopic equipment maintenance http://www.jiangrenyiliao.cn 。
