First of all, I'd like to give you some knowledge about the detection line of industrial endoscope. The detection lines of industrial endoscope can be divided into three types: 1. Soft detection line of tungsten wire mesh / metal mesh; 2; 2. Soft metal gooseneck detection line; 3. Flexible and hard glass fiber testing line.

那么如何选择适合我们自己的呢?

So how to choose the right one for us?

钨丝编网的软质检测线是直接与镜头连接在一起不可拆分的，适合对检测空间较小、较短的工件及小管道进行检测。

The soft detection line of tungsten wire netting is directly connected with the lens and can not be separated. It is suitable for the detection of workpieces and small pipes with small detection space and short detection time.

好处在于设备体积较小，整机便携。

The advantages are small size and portable.

要说到弊端，可能就是检测线比较脆弱，一旦出现幅度过大的弯折，可能导致里面的导丝断掉，那么这整根检测线就废掉了。

When it comes to the disadvantages, it may be that the detection line is relatively fragile. Once there is too much bending, the guide wire inside may be broken, so the whole detection line will be discarded.

软金属鹅颈管的检测线也是与镜头连在一起不可拆分的。

The detection line of soft metal gooseneck is also connected with the lens and cannot be separated.

但是它的特点也就很明显了，它可以任意弯曲并确定方向，进入被检测物体时不需要借助外力便可固定方向。

But its characteristic is very obvious. It can bend freely and determine the direction. When entering the detected object, it can fix the direction without the help of external force.


美中不足的是，它不适合对较大较长的管道或工件进行检测。

The shortcoming is that it is not suitable for the detection of large and long pipelines or workpieces.

玻璃纤维的柔性硬质检测线，它的镜头与检测线是分开的，可以选择更换不同功能、大小的镜头来达到咱们的检测效果。

Flexible and hard glass fiber detection line, its lens and detection line are separated, you can choose to replace different functions, size of the lens to achieve our detection effect.

值得一提的是，与钨丝编网的检测线相比，玻璃纤维的检测线对于检测长度来说没有限制，因为检测线本身具有一定的硬度及柔韧度，所以可以根据大家要检测物体的长短来定制，一般来说检测80~100米是没有问题的。

It is worth mentioning that, compared with the detection line of tungsten wire mesh, the detection line of glass fiber has no limitation on the detection length, because the detection line itself has a certain hardness and flexibility, so it can be customized according to the length of the object you want to detect. Generally speaking, it is no problem to detect 80 ~ 100 meters.

说到定制，是一家专业的工业内窥镜制造商，可以满足大家不同的需求。

When it comes to customization, we are a professional manufacturer of industrial endoscopes, which can meet different needs.

一般来说，我们要根据自己需要检测物体的大小来判断，如果被检测物体内径小于10mm且检测长度不超过5m，就推荐用钨丝编网/金属编网的检测线;如果被检测物体内径大于10mm且检测长度超过5m，就推荐大家使用玻璃纤维柔性硬质的检测线，方便长距离推送。

Generally speaking, we should judge according to the size of the object we need to detect. If the inner diameter of the object to be detected is less than 10 mm and the detection length is not more than 5 m, the detection line of tungsten wire mesh / metal mesh is recommended; If the inner diameter of the detected object is greater than 10 mm and the detection length is more than 5 m, it is recommended to use the flexible and hard detection line of glass fiber to facilitate long-distance push.

如果您看完了我的文章还没有学会该如何选择适合您的检测线，就请您联系我们吧!

If you haven't learned how to choose the right test line after reading my article, please contact us!
